Additional admonition types

Ideas
1

Admonitions are a great way of calling out sections of notes and as great as note and warning are; it would be even better if there were other types of admonitions available. e.g. tip, success, question, etc.

Admonitions - Material for MkDocs has a good list of types.

4 Likes
Community forum archive
2

This is not very hard to implement I think. Could you create a GitHub issue for it?

2 Likes
3

Just added! Additional admonition types Ā· Issue #783 Ā· silverbulletmd/silverbullet Ā· GitHub

2 Likes
4

With the help of @onespaceman here I went ahead and replicated the admonitions mentioned by @SONDLecT in the original post (Admonitions - Material for MkDocs)

image1180Ɨ951 25 KB

The following code goes inside the css code block in the STYLES page

```css
.sb-admonition[admonition="abstract"] {
  --admonition-color: dodgerblue;
}

.sb-admonition[admonition="info"] {
  --admonition-color: turquoise;
}

.sb-admonition[admonition="tip"] {
  --admonition-color: #00bfa5;
}

.sb-admonition[admonition="success"] {
  --admonition-color: #00c853;
}

.sb-admonition[admonition="question"] {
  --admonition-color: #64dd17;
}

.sb-admonition[admonition="failure"] {
  --admonition-color: #ff5252;
}

.sb-admonition[admonition="danger"] {
  --admonition-color: #ff1744;
}

.sb-admonition[admonition="bug"] {
  --admonition-color: #f50057;
}

.sb-admonition[admonition="example"] {
  --admonition-color: #7c4dff;
}

.sb-admonition[admonition="quote"] {
  --admonition-color: #9e9e9e;
}
```

Then, I have slashCommands for each one like this one:

Library/Personal/Snippet/info-admonition

---
tags: template
description: Insert an "info" admonition
hooks.snippet.slashCommand: info-admonition
---
> **info** Info
> |^|
9 Likes
Space-Script: Daily Quote
5

In-case anyone had their custom admonitions ā€œbreakā€ with the release of 0.8.4. This PR requires an additional line be added to admonitions:

.sb-admonition-type * {
    display: none;
  }

Example:

.sb-admonition[admonition="abstract"] {
  .sb-admonition-type * {
    display: none;
  }
  --admonition-color: dodgerblue;
}
3 Likes
Admonition in template?
6

Correct,

And just for the sake of simplicity, here is my whole code again, updated:

.sb-admonition[admonition="abstract"] {
  .sb-admonition-type * { display: none; }
  --admonition-color: dodgerblue;
}

.sb-admonition[admonition="info"] {
  .sb-admonition-type * { display: none; }
  --admonition-color: turquoise;
}

.sb-admonition[admonition="tip"] {
  .sb-admonition-type * { display: none; }
  --admonition-color: #00bfa5;
}

.sb-admonition[admonition="success"] {
  .sb-admonition-type * { display: none; }
  --admonition-color: #00c853;
}

.sb-admonition[admonition="question"] {
  .sb-admonition-type * { display: none; }
  --admonition-color: #64dd17;
}

.sb-admonition[admonition="failure"] {
  .sb-admonition-type * { display: none; }
  --admonition-color: #ff5252;
}

.sb-admonition[admonition="danger"] {
  .sb-admonition-type * { display: none; }
  --admonition-color: #ff1744;
}

.sb-admonition[admonition="bug"] {
  .sb-admonition-type * { display: none; }
  --admonition-color: #f50057;
}

.sb-admonition[admonition="example"] {
  .sb-admonition-type * { display: none; }
  --admonition-color: #7c4dff;
}

.sb-admonition[admonition="quote"] {
  .sb-admonition-type * { display: none; }
  --admonition-color: #9e9e9e;
}
6 Likes
7

If this isnā€™t reloading for someone properly, try toggling sync/online mode on and off.

1 Like
8

Not sure when this change happened, as it was apparent already when I started using SilverBullet, but the icons wonā€™t show up anymore unless you also include this line:

.sb-admonition-type::before {
    width: var(--admonition-width) !important;
}

So, full example for success would be:

.sb-admonition[admonition="success"] {
  .sb-admonition-type * { display: none; }
  .sb-admonition-type::before { width: var(--admonition-width) !important }
  --admonition-color: #00c853;
}
1 Like
9

This was changed in March to fix another bug. The PR that changed this is here: fix(quote): prevent extra indent when first word is not an admonition by janssen-io Ā· Pull Request #1295 Ā· silverbulletmd/silverbullet Ā· GitHub

The documentation is updated too (Markdown/Admonitions), but itā€™s good to mention it here as well! :slight_smile:

I hope it didnā€™t take you too long to figure it out!

2 Likes
10

Full implementation. Thanks to this forum


.sb-admonition-type::before {
    width: var(--admonition-width) !important;
}
.sb-admonition[admonition="abstract"] {
  --admonition-color: dodgerblue;
}

.sb-admonition[admonition="info"] {
  --admonition-color: turquoise;
}

.sb-admonition[admonition="tip"] {
  --admonition-color: #00bfa5;
}

.sb-admonition[admonition="success"] {
  --admonition-color: #00c853;
}

.sb-admonition[admonition="question"] {
  --admonition-color: #64dd17;
}

.sb-admonition[admonition="failure"] {
  --admonition-color: #ff5252;
}

.sb-admonition[admonition="danger"] {
  --admonition-color: #ff1744;
}

.sb-admonition[admonition="bug"] {
  --admonition-color: #f50057;
}

.sb-admonition[admonition="example"] {
  --admonition-color: #7c4dff;
}

.sb-admonition[admonition="quote"] {
  --admonition-color: #9e9e9e;
}

admonitionList={
  "note",
  "abstract",
  "info",
  "tip",
  "success",
  "question",
  "warning",
  "failure",
  "danger",
  "bug",
  "example",
  "quote",
  "warning",
  "note"
}
for i, v in ipairs(admonitionList) do
    slashcommand.define {
      name = "admo-"..v,
      description= "admonition for "..v,
      run = function()
      tpl="> **"..v.."** "..v.."\n"
      tpl=tpl.."> |^|\n"
      editor.insertAtCursor(tpl, false, true)
      end
   }
end
4 Likes
11

Hi @malys

Thanks for posting. I have one question: The admonitionList={} in your 2nd snippet contains more admonition types than are defined in your first snippet.

Example: note is in the list, but not defined.

Why is this?

Thanks and best regards,

Pascal

1 Like
12

I guess itā€™s because note and warning are in standard library code already included (see Library/Std/Slash Templates/*-admonition, but as you see the naming pattern is different).

@malys Nice work!

I will replace the SVGs with custom, the overall style of them is not as coherent as it should be (for example the circular icons diverge significantly from the rest of the icons). But I especially like the way to used Lua to iterate and generate all the commands from a list. Thatā€™s exactly what @zef likes to see - the ways people use the SBs capabilities. :+1:

1 Like
13

note and warning are yet available but i have included them to have a common slash command.

2 Likes
14

Share improvements :slight_smile:

1 Like
15

Here. But I had to also add minor tweaks for the CSS to look better (e.g., the icon alignment with the text was wrong and I guess that hack you see there will work for me only because I did more tweaks in the Silverbullet v2ā€™s CSS already). But I am still completely unsatisfied with them. I would like to look them more like as seen, e.g., here (the icons used in the gist are from that project, btw.).

4 Likes
16

I will not work on that but when you will be ready with the final version, I can test it and give you my feedback

2 Likes
17

Shoutout to @paletochen @mjf @malys and @i_am_dangry. without their previous effort, I couldnā€™t make this multilingual (:united_kingdom: :germany: :france: :italy: :china: :spain:) custom admonition collection.

you just need to add this library and following configuration to chose the desired language:

config.set("admonLang","de")

I also tried to add a top and bottom border to make it pop more, but the structure of the editor doesnā€™t really let me use the correct selectors.top border is easy because it has its own admonition-title class, but the bottom one I donā€™t know how to address it. might give later a try, but for now Iā€™m pretty happy with the results.

4 Likes
18

Perfect. A good improvement! I will remove it from my library. :slight_smile:

1 Like
19

I Updated my Library for the Multilingual Custom Admonition:

I spent the last two days tinkering around in Space-Style and Space-Lua until I figured it out how to add a bottom border. now i finally have a variant I like, and i think @mjf you might like it too.

I added the option to customize the border and inside padding using variables. so everyone can freestyle it to their liking.

I switched it back to the ā€œoldā€ icons (sorry but I liked them better)

Here are just a couple of styling examples:

Default:
title padding 0.5em
text padding: 1em
border width: 2px
border style: solid
border radius: 10px

image1438Ɨ891 110 KB

Dotted:
title padding 0.5em
text padding: 1em
border width: 4px
border style: dotted
border radius: 15px

image1432Ɨ913 141 KB

Wide Padding and Ridge style:
title padding 1em
text padding: 2em
border width: 6px
border style: ridge
border radius: 15px

image1460Ɨ966 95 KB

No Border:
title padding 0.5em
text padding: 1em
border width: 2px
border style: none
border radius: 20px

image1439Ɨ871 113 KB

In the future i might also add the font-size variables too, so you can customize that too.

[EDIT]: Added also the possibility to easily customize the sIze & weight of the title, and the size of the normal admonition text.

image1191Ɨ894 98.5 KB

3 Likes
Better documentation
20

Also updated the slash commands to transform the current line to the chosen admonition, comes in handy when you already have the text and want to turn it into an admonition:

admonition

playing around with the admonitions this weekend made me discover this weird behavior of texts following the admonition. these are the 3 scenarios behaving differently:

Scenario 1:

-the <div> following the admonition gets a sb-line-blockquote class and the <span> sb-quote class. as if the admonition ā€œbleedsā€ into the normal text.

image354Ɨ138 5.83 KB

image678Ɨ214 6.36 KB

Scenario 2:

if I leave an empty line between admonition and next line, everything is fine no extra classes:

image435Ɨ177 6.18 KB

image680Ɨ177 5.45 KB

Scenario 3:

if i put an empty line as the last line inside the admonition, the line following the admonition doesnā€™t get those extra classes either:

image419Ɨ194 6.33 KB

image730Ɨ187 6.68 KB

so my question is, is this intended for some reason, or is it a bug? i didnā€™t found any reported issue on this on github. can this be corrected easily? as a workaround i can use Scenario 2 and 3, but I wondered can this be repaired in the source code?

@zef ?

[Edit]After w quick chat with ChatGPT, showing it the client/codermirror/admonition.ts and the issue. This was the answer:

The short version: the parser (Lezer) still considers the line following your admonition as part of the same blockquote unless thereā€™s a truly empty line to break the Markdown block.

Hereā€™s the anatomy of your misery:

  1. The Markdown parserā€™s behaviour

Markdown blockquotes work like this:

> quote line
next line ā† still part of blockquote unless thereā€™s a blank line

So unless you explicitly separate with an empty line, the parser wraps both the admonition and the next non-> line inside the same Blockquote node in the syntax tree.

Thatā€™s your Scenario 1.
The

and with sb-line-blockquote and sb-quote are the renderer saying ā€œStill in blockquote mode, boss.ā€

  1. Your plugin logic assumes the Blockquote node is only the admonition

Your code sees type.name === ā€œBlockquoteā€ and then slices the entire node text:

const rawText = state.sliceDoc(from, to);

If the parser decided that the next paragraph is part of that same Blockquote node, congratulations: youā€™re styling it too.
Thereā€™s no check that the block actually ends where your admonition does.

  1. Why Scenarios 2 and 3 behave

Scenario 2: You leave an empty line.
ā†’ Markdown sees that as the end of the blockquote.
ā†’ Lezer creates a new node for the next paragraph.
ā†’ Your decorations apply cleanly to only the admonition.

Scenario 3: You end your admonition with an empty quoted line (>) or a blank line inside it.
ā†’ That signals the blockquote has formally ended before the next line.
ā†’ Same result as above ā€” clean separation.

  1. The fix (pick your poison)

Youā€™ve got options:

A. Detect the end of the admonition yourself
Add logic to stop decorating once the regex match ends, instead of trusting the Blockquote nodeā€™s to.

B. Preprocess your Markdown
Ensure a blank line follows every admonition before parsing ā€” cheap and effective.

C. Parse stricter
Modify your regex or use ADMONITION_LINE_SPLIT_REGEX to ensure you only capture consecutive > lines as the admonition body.

3 Likes
